891Overall Control Panel Settings (Config Menu)
Chapter 19 Control Panel Setup (Panel)
Inhibiting Utility 2 Bus and Key Operations
You can inhibit operations on the utility 2 bus and keys 1 to 4 of the M/E and
PGM/PST banks by menu operations.
This inhibitions apply for the following control blocks.
• Cross-point control block
• Transition control block
• Independent key transition control block
1)
1) Only when the Key1, 2 or Key 3, 4 are assigned by the Compact Key Module Assign menu.
Note
This operation cannot be done in the CCP-9000/9000A.
1
In the Panel >Config menu, press [M/E Operation Inhibit].
M/E Operation Inhibit menu appears.
2
In the list in the status area, using any of the following methods, select the
switcher bank for which operations are to be inhibited.
• Press directly on the desired switcher bank in the list.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
3
In the <M/E Operation Inhibit> group, press the utility 2 bus or key button
([Util2 Bus] or [Key1] to [Key4]) for which operations are to be inhibited.
Assigning Functions to the Menu Control Block Top
Menu and User Preference Buttons
To these 41 buttons, you can freely assign a menu recall or user preference
button function.
For details of the menu control block, see Chapter 2 (Volume 1).
1
In the Panel >Config menu, press [Link/Program Button].
The Link/Program Button menu appears.
2
Press [Menu Panel].
Knob Parameter Adjustment Setting values
1 Bank Switcher bank selection for
inhibiting operations
1 to 4
To Next Page
