Chapter 19 Control Panel Setup (Panel)
900
Cross-Point Settings (Xpt Assign Menu)
A confirmation message appears, asking whether or not to execute the
copy.
4 To execute the copy, press [Yes], and to cancel the operation, press [No].
Selecting Cross-Point Assign Tables
You can select the cross-point assign table to be used for each of the following
banks or buses.
• M/E-1 bank and PGM/PST bank
• Buses assignable to AUX delegation buttons
Note
It is not possible to assign cross-point tables 5 to 14 to a bus of a switcher
operated by an MKS-8080/8082 AUX Bus Remote Panel.
1 In the Panel >Xpt Assign menu, using any of the following methods, select
the switcher bank or bus.
• Press directly on the list on the left of the status area.
• Press the arrow keys on the list on the left to scroll the reverse video
cursor.
• Turn the knobs.
2 Using any of the following methods, select the table.
• Press directly on the list on the right of the status area.
• Press the arrow keys on the list on the right to scroll the reverse video
cursor.
• Turn the knob.
3 Press [Table Assign Set].
This sets the table for the selected switcher bank or bus.
Knob Parameter Adjustment Setting values
1 Bank/Bus No Switcher bank or
bus selection
1 and upwards
2 Num Number of
selected switcher
banks or buses
1 and upwards
Knob Parameter Adjustment Values
3 Table No Selection of table
to be assigned
1 to 15
