537DME Special Effect Operations
Chapter 11 DME Operations
For details of Priority, Wind Freeze Timing, Wind Eraser, Defocus, Dust, and
Combine Process in the Wind menu, see “Trail Settings” (page 527).
Spotlighting Settings
You can set up to three light sources (lights 1 to 3).
Notes
• The Spotlighting effect is not supported on the MVE-8000A.
• The BZS-9471 Texture Lighting Software (for BKDS-9470) or BZDM-9050
Texture Lighting Software (for MVE-9000) is required to set lights 2 and 3.
• When the global effect Combiner is enabled, the settings of the smallest-
numbered channel selected for the Combiner are used.
Adjustments to the image surface
The following adjustments can be made to the image surface struck by the
light.
• Adjusting the brightness of the whole image
• Selecting the image surface effect
• Test sphere function
• Adjusting the bumpiness of the image surface
• Coordinate axis on surface of image
• Texture deformations
Selecting the image surface effect
Flat: The image surface is unchanged, causing the selected light source to
appear as the effect.
Texture: A texture appears on the surface of the image. Textures can be
selected from among 30 patterns.
See “Texture Patterns” (page 804) for the texture patterns.
Knob Parameter Adjustment Setting values
1 Amp H Horizontal amplitude of the
wave
0.00 to 100.00
2 Freq H Horizontal frequency of the
wave
–100.00 to +100.00
3 Amp V Vertical amplitude of the
wave
0.00 to 100.00
4 Freq V Vertical frequency of the
wave
–100.00 to +100.00
