Chapter 11 DME Operations
536
DME Special Effect Operations
Selecting the signal for the afterimage portion
In the <Wind Source> group, select the image to fill the afterimage portion.
Notes
• “Mix Color”or “Ext Video”can only be applied to one of the background (see
page 552), flex shadow (see page 464), trail (see page 527), and wind effects.
If you select “Mix Color”or “Ext Video” in the wind settings, a selection of
“Mix Color”or “Ext Video” in any of the other effects is disabled, and “Flat
Color” is selected in its place.
• When executing combining four channels of DME images, “Mix Color” and
“Ext Video” cannot be selected.
Freeze Video: Freeze the input image to use as the afterimage.
Flat Color: Use a single color matte for the afterimage; you can set the
following parameters with the knobs.
Hue Rotate: Use a single color matte with the hue changing for each frame as
the afterimage; you can set the following parameters with the knobs.
Mix Color: Insert a mix color signal (see page 475) in the afterimage portion.
Ext Video: Insert the external video signal input to the Ext IN connector in the
afterimage portion.
Rainbow: Use a freeze image with the hue changing every frame in the
afterimage portion. The difference from “Hue Rotate” is that many colors
appear simultaneously.
For details of the Rainbow parameters, see the “Hue Rotate” item above.
Applying modulation to the afterimage portion (Modulation)
1
In the Wind menu, press [Modulation], turning it on.
2
Set the following parameters.
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Speed Rate at which hue changes –12.00 to +12.00
