Chapter 18 System Setup (System)
838
System Settings (System Config Menu)
Specifying the DME Connected to the Switcher
1
In the System >System Config menu, press [Switcher Assign].
The Switcher Assign menu appears.
2
Using either of the following methods, select the switcher to which the
settings apply.
• In the list appearing in the menu, press the desired device name.
• Press the arrow keys to scroll the reverse video cursor.
The selected switcher appears in reverse video.
If there is only one switcher on the network, carry out the SWR1 setting
(for the first switcher) only.
3
Make the DME settings as follows.
• When making DME settings for SWR1 (the first switcher), for the
first DME, select [DME1] in the <1st DME> group.Turn all buttons in
the <2nd DME> group off.
• When making DME settings for SWR2 (the second switcher), for the
first DME, select [DME3] in the <1st DME> group. Turn all buttons in
the <2nd DME> group off.
Setup in “Dual Simul” mode
When the system operation mode (see page 836) is set to “Dual Simul,” the
following setting is required for setup of the two switchers and connected DME
units.
In the <Setup Target> group, set the [System 1] or [System 2] button to On,
then carry out the setup. You can also set both to On, and make the settings
simultaneously on the two systems.
To Next Page
