Chapter 19 Control Panel Setup (Panel)
894
Cross-Point Settings (Xpt Assign Menu)
Creating the main table
In the main table, a pair consisting of a video signal and a key signal is assigned
to each button number. You can also assign the same signal to another button
number at the same time. Further, you can delete currently assigned signals
from the main table.
To create the main table, use the following procedure.
1
In the Panel >Xpt Assign menu or Panel >Xpt Assign >Table1 (Table2,
Table3, or Table4) menu, press [Main, V/K Pair Assign].
The Main, V/K Pair Assign menu appears.
The left of the status area shows the video and key signal names, source
number, and audio mixer cross-points (machine numbers) currently
assigned in the main table. On the right is a list of the source numbers and
signals that can be assigned. When the shift button is pressed, the number
column is distinguished by color.
For details of audio mixer cross-point assignment operations, see “Setting
the audio mixer cross-points” (page 902).
2
Using any of the following methods, select the button number.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
3
When assign
ing a video
signal, press
[Video] in
the <Assign> gro
up.
When assigning a key signal, press [Key]. (You can select a video signal
and a key signal at the same time.)
Note
[Video] and [Key] in the <Assign> group cannot be turned off at the same
time. At least the one or the other is always on.
4
Use any of the following methods to select the signal to assign.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
5
Using the buttons in the <Xpt Assign> group, assign the selected signal to
the button number currently selected in the main table.
Knob Parameter Adjustment Setting values
1 V/K Pair No Selection of video and key pair number 1 to 128
Knob Parameter Adjustment Setting values
3 Source No Selection of source to be assigned 1 to 128
To Next Page
