Chapter 22 DCU Setup (DCU)
1010
Serial Port Settings (Serial Port Assign Menu)
When setting the video port number
a) 0: No assignment
When setting the response speed
9 Press [Set].
This confirms the setting.
10 If required, repeat steps 4 to 9, to set other items.
Making detailed settings for an Extended VTR
1 In the DCU >Serial Port Assign menu, select the setting target (DCU1 or
DCU2) from the <DCU Select> group.
2 Using any of the following methods, select the serial port connected to the
Extended VTR for which you want to make the settings.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
a) The range of setting values depends on the DCU port setting. (When the MKS-2700 is
connected, select 2 for the slot and a value in the range 1 to 6 for the port.)
3 Press [Port Setting].
The DCU >Serial Port Assign >Extended VTR Setting menu appears.
At the top of the status area, the relevant serial port, slot number, protocol,
serial port name, and SCU number appear. In the lower part of the status
area, the response speed settings appear.
4 Using any of the following methods, specify the command to which the
response speed setting applies.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
Knob Parameter Adjustment Setting values
2 Setting Video port number
0 to 127
a)
Knob Parameter Adjustment Setting values
2 Setting Response speed 0 to 255
Knob Parameter Adjustment Setting values
1 Port No Serial port number
1 and upwards
a)
