192
Key Setting Operations With the Key Control Block
Chapter 4 Keys
Selecting a normal edge
When all five edge type selection buttons are off, a normal edge is selected. If
one of the buttons is lit, press it, turning it off.
Softening the edge
Press the [SOFT EDGE] button, turning it on. The button lights green, and you
can now adjust the softness with the knob.
• For a normal edge, when [SOFT EDGE] is enabled, “Key Drop” mode turns
on.
• When a luminance key or linear key is selected as the key type, and clean
mode is enabled, enabling [SOFT EDGE] ends the clean mode.
Applying the zabton effects
When the [ZABTN] button is lit green, adjust the following parameters.
Press the [MORE] button lit amber, changing it to green, then adjust the
following parameters.
Knob Parameter Setting values
1 Width 0 to 4
2 Position 359 to 0
4 Density 0 to 100
Knob Parameter Adjustment Setting values
1 Soft Edge softness 0 to 100
Knob Parameter Adjustment Setting values
1 Size Pattern size 0 to 100
2 Soft Pattern edge softness 0 to 100
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0 to 100
2 Saturation Saturation 0 to 100
3 Hue Hue 359 to 0
4 Density Density 0 to 100
