Basic Procedure for Wipe Settings
Chapter 5 Wipes
Main and sub modifier link function
When carrying out a pattern mix, it is possible to link the modifier settings for
the main pattern and sub pattern. There are two modes for this function.
FULL LINK (fully linked) mode
In this mode, all modifier settings are the same for the main pattern and sub
pattern.
Changing the modifier settings for one pattern automatically changes the
settings for the other.
SEMI LINK (semi-linked) mode
Only the parameter settings of the modifiers are linked. The modifier on/off
settings are not linked. When the parameter values for the modifiers of the main
pattern and sub pattern are different, then after this link mode is selected,
changing the value of a parameter for one pattern changes the value of the
parameter for the other pattern to maintain the same difference between the
two.
Note
When carrying out a wipe transition using a pattern mix, it is recommended that
you set the modifier link function to “FULL LINK” mode.
If the link function is off, or SEMI LINK mode is selected, the desired effect
may not be obtained at the start or end of the transition.
Combining two patterns
You can combine two selected patterns (referred to as main and “sub”) to form
a new pattern. Select a main pattern in the Main Pattern menu, then use the
following procedure.
1
In the M/E-1 >Wipe menu, select HF3 ‘Sub Pattern.’
The Sub Pattern menu appears.
2
In the same way as for the main pattern, select the sub pattern.
The patterns that can be selected for the sub pattern depend on the pattern
selected for the main pattern (see the following table).
