247Basic Procedure for DME Wipe Settings
Chapter 6 DME Wipes
a) The horizontal center position of the video pasted on Side V. At –100.00 the center is at the left
edge of the screen, and at +100.00 the center is at the right edge of the screen.
b) The vertical center position of the video pasted on Side V. At –100.00 the center is at the bottom
edge of the screen, and at +100.00 the center is at the top edge of the screen.
When Frame in-out (for two channels) is selected
• Pattern numbers 2851 to 2854
• Pattern numbers 2861 to 2864
When Brick (for three channels) is selected (pattern number 3601)
a) Shared with knob 3 for parameter group 2
b) The horizontal center position of the video pasted on Side V. At –100.00 the center is at the left
edge of the screen, and at +100.00 the center is at the right edge of the screen.
c) The vertical center position of the video pasted on Side V. At –100.00 the center is at the bottom
edge of the screen, and at +100.00 the center is at the top edge of the screen.
Knob Parameter Adjustment Setting values
5 Delay Timing for video selected on
a utility bus to appear on the
screen
–100.00 to +100.00
Knob Parameter Adjustment Setting values
1 Rot X Rotation about the Y axis
(horizontal direction)
–100.00 to +100.00
2 Rot Y Rotation about the X axis
(vertical direction)
–100.00 to +100.00
3 Rot Z Rotation about the Z axis –100.00 to +100.00
5 Delay Timing for video selected on
a utility bus to appear on the
screen
–100.00 to +100.00
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 Side V Size X Side V horizontal
magnification
0.01 to 8.00
2 Side V Size Y Side V vertical
magnification
0.01 to 8.00
3 Height Height of brick
0.01 to 100.00
a)
4 Side V Center X Side V horizontal center
position
–100.00 to +100.00
b)
5 Side V Center Y Side V vertical center
position
–100.00 to +100.00
c)
