253Basic Procedure for DME Wipe Settings
Chapter 6 DME Wipes
Display indications when multiple channels are selected at the same
time
The indications on the knobs show the settings of the lowest-numbered
channel. When you turn the knobs to adjust the settings, this changes the
settings on the other channels by the same amount.
In 16:9 mode, to crop to 4:3 aspect ratio
In the <Crop Mode> group, press [4:3], turning it on.
To set the action when a DME wipe crop transition is executed
1
In the M/E-1 >DME Wipe menu, select HF5 ‘Modify.’
The Modify menu appears.
2
Depending on whether the selected pattern is in one-channel mode or two-
channel mode, proceed as follows.
For a pattern in one-channel mode: in the <Ch Select> group, press [1st
Ch], turning it on.
For a pattern in two-channel mode: from the <Ch Select> group, select
the corresponding channels. You can select more than one channel at
the same time.
3
In the <Crop Mode> group, press [Crop] or [4:3 Crop] (to crop from 16:9
to 4:3 aspect ratio), turning it on.
4
In the <Crop Mode> group, press [Remove From Begin].
The Remove From Begin menu appears.
5
In the <Crop Transition> group, select the execution mode for the DME
wipe crop transition.
Cut: Cut mode. The cropping does not change during the transition, but at
the end point of the transition the cropping is removed (enlarges).
Last 5%: The cropping is maintained for the first 95% of the transition,
and is progressively removed during the last 5% of the transition
(enlarges).
Knob Parameter Adjustment Setting values
1 Top Crop the top of the image –100.00 to +100.00
2 Left Crop the left of the image –100.00 to +100.00
3 Right Crop the right of the image –100.00 to +100.00
4 Bottom Crop the bottom of the image –100.00 to +100.00
