Chapter 11 DME Operations
452
DME Special Effect Operations
3 Set the parameters.
The valid ranges of the parameter values depend on the aspect ratio (4:3/
16:9) selected in the system, as follows.
•4:3 mode
• 16:9 mode
Signs of numeric settings
For H, V, and All settings, the sign (+/–) of the setting need not be
considered. For example, in the case of an H setting, the value for Left is
automatically regarded as a negative value, and the value for Right as a
positive value, to display the image.
The following is an example of these settings.
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 H Crop positions on left and right
sides
Left value shown
2 V Crop positions on top and
bottom sides
Top value shown
3 All Crop positions on all sides Left value shown
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Top Crop position on top side –3.00 to +3.00
2 Left Crop position on left side –4.00 to +4.00
3 Right Crop position on right side –4.00 to +4.00
4 Bottom Crop position on bottom side –3.00 to +3.00
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 H Crop positions on left and right
sides
Left value shown
2 V Crop positions on top and
bottom sides
Top value shown
3 All Crop positions on all sides Left value shown
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Top Crop position on top side –2.25 to +2.25
2 Left Crop position on left side –4.00 to +4.00
3 Right Crop position on right side –4.00 to +4.00
4 Bottom Crop position on bottom side –2.25 to +2.25
