461DME Special Effect Operations
Chapter 11 DME Operations
Radial Gradation and Radial Rainbow parameters
Rainbow Gradation parameters
The valid ranges of the parameter values depend on the aspect ratio (4:3/
16:9) selected in the system, as follows.
•4:3 mode
• 16:9 mode
3 When Gradation Matte or Rainbow Matte is selected, set modifiers as
required.
• When turning [Angle] on in the <Rotation> group and slanting the
pattern
a) –1.00 is one rotation in counterclockwise direction. +1.00 is one rotation in clockwise
direction. 0.00 is no rotation.
• When turning [Speed] on in the <Rotation> group and rotating the
pattern at a specified speed
Knob Parameter Adjustment Setting values
3 Soft Softness of gradation border
region
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 H Position of gradation border in
horizontal direction
–8.00 to +8.00
2 V Position of gradation border in
vertical direction
–6.00 to +6.00
3 RBW Soft Softness of rainbow border region 0.00 to 100.00
4 GRD Soft Softness of gradation border
region
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 H Position of gradation border in
horizontal direction
–8.00 to +8.00
2 V Position of gradation border in
vertical direction
–4.50 to +4.50
3 RBW Soft Softness of rainbow border region 0.00 to 100.00
4 GRD Soft Softness of gradation border
region
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Angle Rotation angle of pattern
–8.00 to +8.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation speed of pattern
–100.00 to +100.00
a)
