463DME Special Effect Operations
Chapter 11 DME Operations
• Color 3 settings
Note
Color 3 can be set only when [Rainbow Gradation] is selected in the <Art
Edge Source> group.
Relationship between Hue and Hue Offset
For example, when the Hue value of Color 1 is 180.00, and the Hue Offset
value of Color 2 is –540.00, the relationship is as shown below, with the
hue changing within the Hue Offset range of Color 1 and Color 2.
Rounding art edge corners
Press [Round Corner], turning it on.
The art edge corners on the inner and outer sides are rounded.
Note
This function is available only when [Soft] is on.
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Offset Hue range –540.0 to +540.0
540
360
180
0
-
180
-
360
-
540
Color 1
Hue
Offset
Color 2
Hue setting
range
Hue Offset
setting range
