Chapter 11 DME Operations
472
DME Special Effect Operations
a) For 4:3 mode
b) For 16:9 mode
Note
When pattern number 304 is selected, the effect of settings in the <Edge>
group varies with the Size setting.
To invert the regions of the cropping
In the Wipe Crop menu, press [Invert], turning it on.
Setting the aspect ratio of the wipe crop pattern (Aspect)
1
In the Wipe Crop menu, press [Aspect], turning it on.
2
Set the following parameter.
a) When set to a negative value, the image is stretched vertically, to become taller.
When set to a positive value, the image is stretched horizontally, to become wider.
Rotating the wipe crop pattern (Rotation)
1
In the <Rotation> group of the Wipe Crop menu, select one of the
following.
Angle: Incline the pattern through a fixed angle.
Speed: Rotate the pattern at a fixed speed.
2
Depending on the selection in step 1, set the following parameter.
• When Angle is selected
Knob Parameter Adjustment Setting values
1 H Horizontal position –8.00 to +8.00
2 V Vertical position
–6.00 to +6.00
a)
–4.50 to +4.50
b)
3 Size Pattern size 0.00 to 100.00
5 Pattern Pattern number 1 to 24, 304
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation
–8.00 to +8.00
a)
To Next Page
