• When Draw is selected
a) 100.00 gives an image completely transformed by the Sketch effect. 0.00 is the original
input image.
b) The larger the Clip value, the narrower the outline width.
• When Relief is selected
a) 100.00 gives an image completely transformed by the Sketch effect. 0.00 is the original
input image.
• When Sharp is selected
5 If you selected other than Sharp in step 3, depending on the necessity,
proceed as follows.
• To adjust the outline color for Edge Color or Draw
Turn [Edge Matte] on and set the following parameters to set the outline
color.
Knob Parameter Adjustment Setting values
1 Mix Mix amount for Draw video and
input video
0.00 to 100.00
a)
2 Clip Reference level for outline
extraction
–100.00 to +100.00
b)
3 Gain Image gain for outline extraction –100.00 to +100.00
Knob Parameter Adjustment Setting values
1 Mix Mix amount for Relief video and
input video
0.00 to 100.00
a)
2 Offset Relief luminance level –100.00 to +100.00
3 Gain Image gain for outline extraction –100.00 to +100.00
4 Angle Direction of relief image light
source
–8.00 to +8.00
Knob Parameter Adjustment Setting values
1 H Simultaneously adjust the left and
right resolution
0.00 to 100.00
2 V Simultaneously adjust the top and
bottom resolution
0.00 to 100.00
3 All Simultaneously adjust the
resolution of all four sides
0.00 to 100.00
5 Coring Minimum value of edge to
emphasize
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
