Chapter 11 DME Operations
500
DME Special Effect Operations
• When H&V mode is selected
• When Size mode is selected
To smooth the range envelope when the wave range is limited
1 Press [Range Envelope], turning it on.
2 Set the following parameters.
• When H&V mode is selected
Knob Parameter Adjustment Setting values
1 Size H Amount of horizontal wave
modulation
0.00 to 100.00
2 Offset H Center point of horizontal
modulation range
–8.000 to +8.000
3 Size V Amount of vertical wave
modulation
0.00 to 100.00
4 Offset V Center point of vertical
modulation range
–8.000 to +8.000
Knob Parameter Adjustment Setting values
1 Size H Amount of wave modulation 0.00 to 100.00
2 Offset H Center point of modulation
range
–8.000 to +8.000
Envelope
Size
Offset
Knob Parameter Adjustment Setting values
1 Envelope H Smoothness of envelope in
horizontal direction
0.00 to 100.00
2 Envelope V Smoothness of envelope in vertical
direction
0.00 to 100.00
