Chapter 11 DME Operations
502
DME Special Effect Operations
a) Set when Lock is on.
b) Set when Lock is off.
To stop the waves
Press [Lock], turning it on.
With each press, the waves alternately stop and start moving again.
To select the waveform
Press [Form] and set the following parameters.
a) 1 (SINE): Sine wave
2 (PARABOLA): Parabola wave
3 (TRIANGLE): Triangular wave
4 (RECTANGLE): Rectangular wave
5 (CIRCLE): Circular wave
6 (CUBIC): Cubic wave
Ripple settings
There are four modes: Radial, Angular, Both, and Shape. The direction of
modulation differs depending on the mode. You can set the size and frequency
of the ripples, their direction and speed, their center point, and other
parameters. In Shape mode, you can select ripple shapes other than circles
(stars, etc.).
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 Amp V Amplitude of twist in vertical direction 0.00 to 100.00
2 Freq V Frequency of twist in vertical direction 0.00 to 100.00
3
Offset V
a)
Amount of movement in twist phase
in the vertical direction
–16.00 to +16.00
4
Speed V
b)
Speed and direction of twist
movement in vertical direction
–100.00 to +100.00
5 Slant Slant of twist –8.000 to +8.000
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Amp H Amplitude of twist in horizontal
direction
0.00 to 100.00
3
Offset H
a)
Amount of movement in twist phase
in the horizontal direction
–100.00 to +100.00
5 Slant Slant of twist –8.000 to +8.000
Knob Parameter Adjustment Setting values
1 Form H Waveform in horizontal direction
1 to 6
a)
2 Form V Waveform in vertical direction
1 to 6
a)
To Next Page
