Sony DVS-9000 System - Page 504

Chapter 11 DME Operations
504
DME Special Effect Operations
a) Set when Lock is on.
b) Set when Lock is off.
• When Both mode is selected
a) Set when Lock is on.
b) Set when Lock is off.
• When Shape mode is selected
2 Freq A Ripple frequency along periphery 0.00 to 100.00
3
Offset A
a)
Direction along periphery in which
to offset ripple phase and amount
of movement
–8.000 to +8.000
4
Speed A
b)
Ripple direction along periphery
and speed
–100.00 to +100.00
5 Amp R Ripple amplitude along radius 0.00 to 100.00
Knob Parameter Adjustment Setting values
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 Amp R Ripple amplitude along radius 0.00 to 100.00
2 Freq R Ripple frequency along radius 0.00 to 100.00
3
Offset R
a)
Direction along radius in which to
offset ripple phase and amount of
movement
–8.000 to +8.000
4
Speed R
b)
Ripple direction along radius and
speed
–100.00 to +100.00
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Amp A Ripple amplitude along periphery 0.00 to 100.00
2 Freq A Ripple frequency along periphery 0.00 to 100.00
3
Offset A
a)
Direction along periphery in
which to offset ripple phase and
amount of movement
–8.000 to +8.000
4
Speed A
b)
Ripple direction along periphery
and speed
–100.00 to +100.00
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 Amp R Ripple amplitude 0.00 to 100.00
2 Freq R Ripple frequency 0.00 to 100.00
3
Offset R
a)
Direction in which to offset ripple
phase and amount of movement
–8.000 to +8.000
4
Speed R
b)
Ripple direction and speed –100.00 to +100.00
