Chapter 11 DME Operations
526
DME Special Effect Operations
Setting the color of the shade in the shade area
1
Turn [Shade Color] on.
2
Adjust the following parameters.
Setting the bar mode of the highlight area
When you select [Bar] in step 3 of “Applying the Lighting effect” (see page
523), use the following procedure to set the bar mode of the highlight area.
Note
The bar mode of the highlight area is not supported on the MVE-8000A.
1
Select the mode in the <Bar Light Mode> group.
Normal: Emphasizes the bar highlight area.
Specular: An effect like light striking a surface with metallic reflections.
Mat: An effect like light striking paper, cloth, or another diffusively
reflective surface.
2
Set the following parameters.
3
When you select Normal or Mat in step 1, press [Bar Diffuse Color],
turning it on, and adjust the following parameters to set the color of the
diffuse light area.
Knob Parameter Adjustment Setting values
1 X X-value of bar center point –8.00 to +8.00
4 Width Width of bar 0.00 to 100.00
5 Soft Softness of edges 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Intensity Intensity of diffuse light area 0.00 to 100.00
2 Offset Offset of center of diffuse light
area
–4.00 to +4.00
3 Width Width of diffuse light area 0.00 to 100.00
4 Soft Softness of diffuse light area 0.00 to 100.00
To Next Page
