571Global Effect Operations
Chapter 11 DME Operations
The valid ranges of the parameter values depend on the aspect ratio
(4:3/16:9) selected in the system, as follows.
•4:3 mode
• 16:9 mode
The set position becomes the upper left corner of Side V or Side H. The
right and bottom sides of the inserted image are set automatically.
Compress: Images are inserted after being compressed. You can set the
following parameters.
The valid ranges of the parameter values depend on the aspect ratio
(4:3/16:9) selected in the system, as follows.
•4:3 mode
• 16:9 mode
Knob Parameter Adjustment Setting values
1 H Position of left crop –4.00 to +4.00
2 V Position of top crop –3.00 to +3.00
3 Rotation Angle of rotation, when rotated
around the Z-axis of the source
space
0/90/180/270°
Knob Parameter Adjustment Setting values
1 H Position of left crop –4.00 to +4.00
2 V Position of top crop –2.25 to +2.25
3 Rotation Angle of rotation, when rotated
around the Z-axis of the source
space
0/90/180/270°
Knob Parameter Adjustment Setting values
1 Top Position of top crop –2.83 to +3.00
2 Left Position of left crop –4.00 to +3.83
3 Right Position of right crop –3.83 to +4.00
4 Bottom Position of bottom crop –3.00 to +2.83
5 Rotation Angle of rotation, when rotated
around the Z-axis of the source
space
0/90/180/270°
Knob Parameter Adjustment Setting values
1 Top Position of top crop –2.12 to +2.25
2 Left Position of left crop –4.00 to +3.87
3 Right Position of right crop –3.87 to +4.00
4 Bottom Position of bottom crop –2.25 to +2.12
