Chapter 14 Snapshots
692
Snapshot Operations From the Numeric Keypad Control Block
a) The GPI port that can be set is 1 (fixed).
For details of attributes, see “Snapshot Attributes” (page 687).
Note
In the numeric keypad control block, it is not possible to apply the cross-
point hold. For details, see “Applying snapshot attributes” (page 695).
7
Press the [ENTER] button.
This saves the snapshot, and the [STORE] button goes off. The [RCALL]
and [STORE STATS] buttons light.
To cancel a snapshot save operation
After saving a snapshot, to cancel the save, hold down the [STORE STATS]
button and press the [UNDO] button.
Recalling a snapshot from the numeric keypad control block
1
In the numeric keypad control block, press the [SNAPSHOT] button,
turning it on.
This allocates the numeric keypad control block to snapshot operations,
and the [RCALL] button lights.
2
Press the region selection button corresponding to the region you want to
recall, turning it on. Multiple selections are also possible.
[M/E 1], [P/P]: These select the M/E-1 and PGM/PST regions.
[USER 1] to [USER 8]: These select the User regions.
[DME 1] to [DME 4]: These select the DME channels.
[RTR]: This selects the Router region.
[ALL]: This selects all regions.
[MASTR]: This selects a master snapshot.
Note
The regions that can be selected simultaneously are those assigned to the
region selection buttons in the numeric keypad control block. (See
“Assigning a Region to a Region Selection Button in the Numeric Keypad
Control Block” in Chpater 19 (Volume 3).)
Attribute to apply Button
Effect dissolve [+/–/EFF DISS] button
Auto transition [CLR/AUTO TRANS] button
GPI output
a)
TRIM/GPI ENBL] button
