Names and Functions of Parts of the Control Panel
Chapter 2 Menus and Control Panel
on the number of DME processor
channels installed.
With the MKS-9011/9012 control
panel, you cannot directly control
DME5 to DME8.
When the [DEV] button is selected: This
enables the VTR/disk recorder/frame
memory operation mode in the device
control block. Each button functions as
follows.
(From upper left to right in the above
figure)
[M/E1] to [M/E3]: DEV1 (device 1) to
DEV3 (device 3)
[P/P]: DEV4 (device 4)
[USER]: FM1CLIP (frame memory
clip 1)
[Unused]: FM2CLIP (frame memory
clip 2)
[DME1] to [DME4]: DEV5 (device 5)
to DEV8 (device 8)
[Unused]: FM LOOP (frame memory
loop)
[DME5] to [DME8]: DEV9 (device 9)
to DEV12 (device 12)
To exit from this mode, press the
[DEV] button again, turning it off.
When the [RUN CTRL] button is
selected: This enables the effect run
control mode in the device control
block.
[RSZR CTRL] button: Cannot be used.
The functions of the operation buttons,
trackball, and Z-ring vary with the
operation mode as follows.
b Operation buttons
When the positioner operation mode is
enabled
K1 CB1: Press this button to enable wipe
pattern position setting for key 1
(DSK1).
When the [USER] button is selected,
pattern position setting for color
background 1 is enabled.
K2 CB2: Press this button to enable wipe
pattern position setting for key 2
(DSK2).
When the [USER] button is selected,
pattern position setting is enabled for
color background 2.
K3: Press this button to enable wipe pattern
position setting for key 3 (DSK3).
K4: Press this button to enable wipe pattern
position setting for key 4 (DSK4).
MAIN: Press this button to enable main
wipe pattern position setting for normal
transitions.
SUB: Press this button to enable sub wipe
pattern position setting for normal
transitions.
Among the [K1 CB1] button, [K2 CB2]
button, [K3] button, [K4] button, [MAIN]
button, and [SUB] button, you can select
multiple buttons.
POS: Press this button to enable pattern
movement in the x-axis and y-axis
directions with the trackball.
When the [USER] button is selected,
this enables the trackball to move the
pattern in the x-axis and y-axis
directions, and the Z-ring to adjust the
size of the pattern.
X, Y: These restrict the axes affected by the
trackball and Z-ring to the x- or y-axis.
Z: This restricts the axes affected by the
trackball and Z-ring to the z-axis.
CTR (center): When this button is pressed,
the pattern position returns to the
center. When the [USER] button is
selected, the pattern size also returns to
50.00.
SHIFT/CLR WORK BUFR: These are
not used in positioner operation mode.
