Cross-Point Settings (Xpt Assign Menu)
Setting the action of the [SHIFT] button in the cross-point control
block
In the <Display Shift Mode> group of the Panel >Xpt Assign >Main, V/K Pair
Assign menu or Panel >Xpt Assign >Table Button Assign menu, select either
of the following.
Display: Functions as a shift button dedicated to the source name displays.
Shift All Bus: Functions as a shift button for all buses.
Notes
• It is not possible to make this setting separately for each of the M/E and
PGM/PST banks.
• “Shift All Bus” is only valid when the cross-point button shift operation (see
previous item) is set to “Lock” or “Off.”
Setting the source signal name
1
In the Panel >Xpt Assign menu or Panel >Xpt Assign >Table Button
Assign menu, press [Src Name/LCD Color].
The Src Name/LCD Color menu appears.
2
Turn the knob to select the signal to be set.
3
Press [Source Name].
A keyboard window appears.
4
Enter any name of not more than 16 characters, then press [Enter].
For details of keyboard window operation, see “Menu Operations” in
Chapter 2 (Volume 1).
Sequential names for multiple signals
When you specify a number at the end of a signal name, all of the signals in the
range selected by knobs 1 and 2 are automatically assigned names ending with
sequential numbers.
Example: To assign sequential names to source signal 2 through source signal
4
1. In step 2 above, set knob 1 to “2,” and set knob 2 to “3.”
2. Set the name of source signal 2 to “CAM2.”
Knob Parameter Adjustment Setting values
1 Source No Source signal selection 1 to 128
2 Num Number of source signals to be
selected
1 to 128
