907Auxiliary Bus Control Block Settings (Aux Assign Menu)
Chapter 19 Control Panel Setup (Panel)
To expand the shift function
To set the [KEY] button as a shift operation expansion button, in the Source
Table Assign menu select the source table, then in the <Expand Xpt Shift
Assign> group, press [Key Button].
In order not to expand the shift operation, press [No Assign] in the <Expand
Xpt Shift Assign> group.
Assigning levels to a level selection button
To assign levels to the [LEVEL1] to [LEVEL4] buttons in the auxiliary bus
control block, use the following procedure.
1
In the Panel >Aux Assign >RTR Mode Setting menu, press [Level Button
Assign].
The Level Button Assign menu appears. The status area shows a list of the
assignment status of levels to each button.
2
In the <Level Button Select> group, select the button you want to set.
3
In the <Level Assign> group, press the levels you want to assign to the
button, turning them on.
You can select plural of levels. You can also make a selection that overlaps
that of another button.
Selecting a destination selection button for a snapshot
To set whether snapshots are recalled for each destination selection button
individually, use the Panel >Aux Assign >RTR Mode Setting menu as follows.
1
Use any of the following methods to select the destination selection button
to which the setting applies.
• Press directly on the list on the left of the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
2
Press [SS Enable], turning it on or off.
On: When a snapshot applying to the router is recalled, the recall also
applies to the selected destination selection button.
Off: When a snapshot applying to the router is recalled, the recall does not
apply to the selected destination selection button.
Knob Parameter Adjustment Setting values
1 Dest No Selection of destination selection
button
1 to 128
To Next Page
