Setting Button Assignments (Prefs/Utility Menu)
a) For the safe title on/off commands (from ME1 PGM1 ST-ME1 PGM4 ST to AUX1 ST-AUX48
ST), the name of the assigned output signal is shown.
Assigning a menu shortcut to a memory recall button
1
Referring to the procedure up to step 3 on “Assigning a Function to a
Memory Recall Button in the Utility/Shotbox Control Block (MKS-8033
Utility/Shotbox Module, Option)” (page 914), select [Menu Shortcut].
The memory recall buttons in the utility/shotbox control block flash
orange.
2
Using any of the following methods, display the menu to which you want
to make a shortcut.
• In the menu control block, press the relevant top menu selection button,
then select VF and HF.
• Press the menu page number button in the upper left corner of the menu
screen, then enter a menu number from the numeric keypad window.
• Press a particular control panel button twice in rapid succession.
3
In the utility/shotbox control block, select the bank, and press the button to
which you want to assign the shortcut.
The menu screen goes back to the Prefs/Utility >Utility Module Assign
menu, and the selection is reflected in the status area.
The buttons in the utility/shotbox control block flash.
4
Repeat steps 2 and 3 as required, to assign all desired menu shortcuts to
the buttons in the utility/shotbox control block.
Macro TL with Region When registering a timeline macro
event, on/off setting of mode to save
applicable region
On Off
DME Override DME override on/off On Off
DME Graphic DME graphics on/off (Applies to
graphics for channel selected in device
control block)
On Off
Plug-In Editor Enbl Enable/disable operation from an
editing keyboard
Enabled Disabled
Inhibit Set Inhibit cross-point button Can be set only
while pressed (lit)
When the function
is assigned
Inhibit All Clear Clear all cross-point button inhibit
settings
Can be set only
while pressed (lit)
When the function
is assigned
Command name
a)
Function Button status
Lit green Lit orange
To Next Page
