943Settings for Switcher Configuration (Config Menu)
Chapter 20 Switcher Setup (Switcher)
Assigning the output of each bank in Multi Program mode
When you selected [Multi Program] as the operation mode, use the following
procedure.
1
In the Switcher >Config menu, press [M/E Output Assign].
The M/E Output Assign menu appears.
2
On the list in the status area, select the bank output to be assigned.
The selected output appears in reverse video.
3
In the <M/E Output Assign> group, select the output signal to be assigned.
Setting the output configuration for each bank
When you selected [Multi Program] or [DSK] as the operation mode, use the
following procedure.
1
In the Switcher >Config menu, press [PGM Config].
The PGM Config menu appears.
The status area shows the background and key configuration assigned to
the output of each bank.
2
Using either of the following methods, select the output for which you
want to make the setting.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
The selected output appears in reverse video.
3
In the <Bkgd> group, select the background.
In Multi Program mode, select [Clean] or [Utility2], then skip to step 5.
In DSK mode, select one of [Bkgd1] to [Bkgd4].
4
In DSK mode, turn the knobs to select the background signal.
Knob Parameter Adjustment Setting values
1 No (PGM) Output to which setting applies 1 to 16
Knob Parameter Adjustment Setting values
2 to 5 Bkgd1 to 4 Background signal selection
1 to 18
a)
