Chapter 20 Switcher Setup (Switcher)
952
Signal Output Settings (Output Menu)
3
Adjust the parameter.
a) Depending on the signal format, the adjustment range varies as follows.
• 480i: 10 to 19
• 576i: 6 to 22
To return the values to their defaults, press [Default].
4
To enable the through mode, press [Through Mode], setting it to Enable.
The through mode can be applied to the following outputs.
• Aux 1 to 48 outputs
• Program outputs of the M/E and PGM/PST rows
• Clean outputs of the M/E and PGM/PST rows
Making safe title settings
1
In the Switcher >Output menu, press [Safe Title].
The Safe Title menu appears.
The status area shows the output ports and the assigned signals, with the
box 1, box 2, and cross states.
2
To enable the safe title on/off setting made in the Misc menu, press [Safe
Title], turning it on.
3
Carry out either of the following operations.
To display a box: Press [Box1] or [Box2], turning it on.
In this case, carry out the following steps 4 and 5.
To display a cross: Press [Cross], turning it on.
4
When you selected [Box1] or [Box2] in step 3, adjust the following
parameters.
a) Adjustable for Box2
5
When in step 3 you selected [Box1] or [Box2], in the <Box1 Adjust> or
<Box2 Adjust> group, select the screen aspect ratio (16:9/14:9/4:3).
Knob Parameter Adjustment Setting values
2 Mask End Final value for vertical blanking
interval
See note a) below
Knob Parameter Adjustment Setting values
2 Box Size Box size 50.00 to 100.00
3 Luminance Display brightness
0.00 to 100.00
a)
