Page #1125 background image
UM1940
LL SPI Generic Driver
DocID028236 Rev 2
1125/1371
65 LL SPI Generic Driver
65.1 SPI Firmware driver registers structures
65.1.1 LL_SPI_InitTypeDef
Data Fields
uint32_t TransferDirection
uint32_t Mode
uint32_t DataWidth
uint32_t ClockPolarity
uint32_t ClockPhase
uint32_t NSS
uint32_t BaudRate
uint32_t BitOrder
uint32_t CRCCalculation
uint32_t CRCPoly
Field Documentation
uint32_t LL_SPI_InitTypeDef::TransferDirection
Specifies the SPI unidirectional or bidirectional data mode. This parameter can be a
value of SPI_LL_EC_TRANSFER_MODE.This feature can be modified afterwards
using unitary function LL_SPI_SetTransferDirection().
uint32_t LL_SPI_InitTypeDef::Mode
Specifies the SPI mode (Master/Slave). This parameter can be a value of
SPI_LL_EC_MODE.This feature can be modified afterwards using unitary function
LL_SPI_SetMode().
uint32_t LL_SPI_InitTypeDef::DataWidth
Specifies the SPI data width. This parameter can be a value of
SPI_LL_EC_DATAWIDTH.This feature can be modified afterwards using unitary
function LL_SPI_SetDataWidth().
uint32_t LL_SPI_InitTypeDef::ClockPolarity
Specifies the serial clock steady state. This parameter can be a value of
SPI_LL_EC_POLARITY.This feature can be modified afterwards using unitary
function LL_SPI_SetClockPolarity().
uint32_t LL_SPI_InitTypeDef::ClockPhase
Specifies the clock active edge for the bit capture. This parameter can be a value of
SPI_LL_EC_PHASE.This feature can be modified afterwards using unitary function
LL_SPI_SetClockPhase().
uint32_t LL_SPI_InitTypeDef::NSS
Specifies whether the NSS signal is managed by hardware (NSS pin) or by software
using the SSI bit. This parameter can be a value of SPI_LL_EC_NSS_MODE.This
feature can be modified afterwards using unitary function LL_SPI_SetNSSMode().
uint32_t LL_SPI_InitTypeDef::BaudRate
Specifies the BaudRate prescaler value which will be used to configure the transmit
and receive SCK clock. This parameter can be a value of
SPI_LL_EC_BAUDRATEPRESCALER.
Note:The communication clock is derived from the master clock. The slave clock does
not need to be set. This feature can be modified afterwards using unitary function
LL_SPI_SetBaudRatePrescaler().
