ST STM32F2

HAL TIM Generic Driver
UM1940
574/1371
DocID028236 Rev 2
uint32_t TIM_OC_InitTypeDef::OCMode
Specifies the TIM mode. This parameter can be a value of
TIM_Output_Compare_and_PWM_modes
uint32_t TIM_OC_InitTypeDef::Pulse
Specifies the pulse value to be loaded into the Capture Compare Register. This
parameter can be a number between Min_Data = 0x0000 and Max_Data = 0xFFFF
uint32_t TIM_OC_InitTypeDef::OCPolarity
Specifies the output polarity. This parameter can be a value of
TIM_Output_Compare_Polarity
uint32_t TIM_OC_InitTypeDef::OCNPolarity
Specifies the complementary output polarity. This parameter can be a value of
TIM_Output_Compare_N_Polarity
Note:This parameter is valid only for TIM1 and TIM8.
uint32_t TIM_OC_InitTypeDef::OCFastMode
Specifies the Fast mode state. This parameter can be a value of
TIM_Output_Fast_State
Note:This parameter is valid only in PWM1 and PWM2 mode.
uint32_t TIM_OC_InitTypeDef::OCIdleState
Specifies the TIM Output Compare pin state during Idle state. This parameter can be a
value of TIM_Output_Compare_Idle_State
Note:This parameter is valid only for TIM1 and TIM8.
uint32_t TIM_OC_InitTypeDef::OCNIdleState
Specifies the TIM Output Compare pin state during Idle state. This parameter can be a
value of TIM_Output_Compare_N_Idle_State
Note:This parameter is valid only for TIM1 and TIM8.
45.1.3 TIM_OnePulse_InitTypeDef
Data Fields
uint32_t OCMode
uint32_t Pulse
uint32_t OCPolarity
uint32_t OCNPolarity
uint32_t OCIdleState
uint32_t OCNIdleState
uint32_t ICPolarity
uint32_t ICSelection
uint32_t ICFilter
Field Documentation
uint32_t TIM_OnePulse_InitTypeDef::OCMode
Specifies the TIM mode. This parameter can be a value of
TIM_Output_Compare_and_PWM_modes
uint32_t TIM_OnePulse_InitTypeDef::Pulse
Specifies the pulse value to be loaded into the Capture Compare Register. This
parameter can be a number between Min_Data = 0x0000 and Max_Data = 0xFFFF
uint32_t TIM_OnePulse_InitTypeDef::OCPolarity
Specifies the output polarity. This parameter can be a value of
TIM_Output_Compare_Polarity
uint32_t TIM_OnePulse_InitTypeDef::OCNPolarity
Specifies the complementary output polarity. This parameter can be a value of
TIM_Output_Compare_N_Polarity
Note:This parameter is valid only for TIM1 and TIM8.
