UM1940
Correspondence
between API reg
isters and A
PI
low-layer driver functi
ons
DocID028236 Re
v 2
1327
/1371
Register
Field
Function
TEIF2
LL_DMA_IsActiveFlag_TE2
TEIF3
LL_DMA_IsActiveFlag_TE3
M0AR
M0A
LL_DMA_ConfigAddresses
LL_DMA_GetM2MDstAddress
LL_DMA_GetMemoryAddress
LL_DMA_SetM2MDstAddress
LL_DMA_SetMemoryAddress
M1AR
M1A
LL_DMA_GetMemory1Address
LL_DMA_SetMemory1Address
NDTR
NDT
LL_DMA_GetDataLength
LL_DMA_SetDataLength
PAR
PA
LL_DMA_ConfigAddresses
LL_DMA_GetM2MSrcAddress
LL_DMA_GetPeriphAddress
LL_DMA_SetM2MSrcAddress
LL_DMA_SetPeriphAddress
71.7
EXTI
Table 31: Correspondence between EXTI registers and EXTI low-la
y
e
r driver functions
Register
Field
Function
EMR
EMx
LL_EXTI_DisableEvent_0_31
LL_EXTI_EnableEvent_0_31
LL_EXTI_IsEnabledEvent_0_31
FTSR
FTx
LL_EXTI_DisableFallingTrig_0_31
LL_EXTI_EnableFallingTrig_0_31
LL_EXTI_IsEnabledFallingTrig_0_31
IMR
IMx
LL_EXTI_DisableIT_0_31
LL_EXTI_EnableIT_0_31
LL_EXTI_IsEnabledIT_0_31
PR
PIFx
LL_EXTI_ClearFlag_0_31
LL_EXTI_IsActiveFlag_0_31
LL_EXTI_ReadFlag_0_31
RTSR
RTx
LL_EXTI_DisableRisingTrig_0_31
LL_EXTI_EnableRisingTrig_0_31
LL_EXTI_IsEnabledRisingTrig_0_31
SWIER
SWIx
LL_EXTI_GenerateSWI_0_31
1326
1328
