ST STM32F2 User Manual

UM1940
LL TIM Generic Driver
DocID028236 Rev 2
1181/1371
Parameters
TIMx: Timer instance
Channel: This parameter can be one of the following values:
LL_TIM_CHANNEL_CH1
LL_TIM_CHANNEL_CH1N
LL_TIM_CHANNEL_CH2
LL_TIM_CHANNEL_CH2N
LL_TIM_CHANNEL_CH3
LL_TIM_CHANNEL_CH3N
LL_TIM_CHANNEL_CH4
Return values
Returned: value can be one of the following values:
LL_TIM_OCPOLARITY_HIGH
LL_TIM_OCPOLARITY_LOW
Reference Manual to
LL API cross
reference:
CCER CC1P LL_TIM_OC_GetPolarity
CCER CC1NP LL_TIM_OC_GetPolarity
CCER CC2P LL_TIM_OC_GetPolarity
CCER CC2NP LL_TIM_OC_GetPolarity
CCER CC3P LL_TIM_OC_GetPolarity
CCER CC3NP LL_TIM_OC_GetPolarity
CCER CC4P LL_TIM_OC_GetPolarity
LL_TIM_OC_SetIdleState
Function name
__STATIC_INLINE void LL_TIM_OC_SetIdleState
(TIM_TypeDef * TIMx, uint32_t Channel, uint32_t IdleState)
Function description
Set the IDLE state of an output channel.
Parameters
TIMx: Timer instance
Channel: This parameter can be one of the following values:
LL_TIM_CHANNEL_CH1
LL_TIM_CHANNEL_CH1N
LL_TIM_CHANNEL_CH2
LL_TIM_CHANNEL_CH2N
LL_TIM_CHANNEL_CH3
LL_TIM_CHANNEL_CH3N
LL_TIM_CHANNEL_CH4
IdleState: This parameter can be one of the following values:
LL_TIM_OCIDLESTATE_LOW
LL_TIM_OCIDLESTATE_HIGH
Return values
None:
Notes
This function is significant only for the timer instances
supporting the break feature. Macro
IS_TIM_BREAK_INSTANCE(TIMx) can be used to check
whether or not a timer instance provides a break input.
Reference Manual to
LL API cross
reference:
CR2 OIS1 LL_TIM_OC_SetIdleState
CR2 OIS1N LL_TIM_OC_SetIdleState
CR2 OIS2 LL_TIM_OC_SetIdleState
CR2 OIS2N LL_TIM_OC_SetIdleState
CR2 OIS3 LL_TIM_OC_SetIdleState
CR2 OIS3N LL_TIM_OC_SetIdleState
CR2 OIS4 LL_TIM_OC_SetIdleState
