ST STM32F2 User Manual

UM1940
HAL TIM Generic Driver
DocID028236 Rev 2
573/1371
45 HAL TIM Generic Driver
45.1 TIM Firmware driver registers structures
45.1.1 TIM_Base_InitTypeDef
Data Fields
uint32_t Prescaler
uint32_t CounterMode
uint32_t Period
uint32_t ClockDivision
uint32_t RepetitionCounter
uint32_t AutoReloadPreload
Field Documentation
uint32_t TIM_Base_InitTypeDef::Prescaler
Specifies the prescaler value used to divide the TIM clock. This parameter can be a
number between Min_Data = 0x0000 and Max_Data = 0xFFFF
uint32_t TIM_Base_InitTypeDef::CounterMode
Specifies the counter mode. This parameter can be a value of TIM_Counter_Mode
uint32_t TIM_Base_InitTypeDef::Period
Specifies the period value to be loaded into the active Auto-Reload Register at the
next update event. This parameter can be a number between Min_Data = 0x0000 and
Max_Data = 0xFFFF.
uint32_t TIM_Base_InitTypeDef::ClockDivision
Specifies the clock division. This parameter can be a value of TIM_ClockDivision
uint32_t TIM_Base_InitTypeDef::RepetitionCounter
Specifies the repetition counter value. Each time the RCR downcounter reaches zero,
an update event is generated and counting restarts from the RCR value (N). This
means in PWM mode that (N+1) corresponds to:the number of PWM periods in edge-
aligned modethe number of half PWM period in center-aligned mode This parameter
must be a number between Min_Data = 0x00 and Max_Data = 0xFF.
Note:This parameter is valid only for TIM1 and TIM8.
uint32_t TIM_Base_InitTypeDef::AutoReloadPreload
Specifies the auto-reload preload. This parameter can be a value of
TIM_AutoReloadPreload
45.1.2 TIM_OC_InitTypeDef
Data Fields
uint32_t OCMode
uint32_t Pulse
uint32_t OCPolarity
uint32_t OCNPolarity
uint32_t OCFastMode
uint32_t OCIdleState
uint32_t OCNIdleState
Field Documentation
