ST STM32F2 User Manual

UM1940
LL WWDG Generic Driver
DocID028236 Rev 2
1299/1371
LL_WWDG_PRESCALER_8
Reference Manual to
LL API cross
reference:
CFR WDGTB LL_WWDG_GetPrescaler
LL_WWDG_SetWindow
Function name
__STATIC_INLINE void LL_WWDG_SetWindow
(WWDG_TypeDef * WWDGx, uint32_t Window)
Function description
Set the Watchdog Window value to be compared to the
downcounter (7-bits W[6:0]).
Parameters
WWDGx: WWDG Instance
Window: 0x00..0x7F (7 bit Window value)
Return values
None:
Notes
This window value defines when write in the WWDG_CR
register to program Watchdog counter is allowed. Watchdog
counter value update must occur only when the counter value
is lower than the Watchdog window register value. Otherwise,
a MCU reset is generated if the 7-bit Watchdog counter value
(in the control register) is refreshed before the downcounter
has reached the watchdog window register value. Physically
is possible to set the Window lower then 0x40 but it is not
recommended. To generate an immediate reset, it is possible
to set the Counter lower than 0x40.
Reference Manual to
LL API cross
reference:
CFR W LL_WWDG_SetWindow
LL_WWDG_GetWindow
Function name
__STATIC_INLINE uint32_t LL_WWDG_GetWindow
(WWDG_TypeDef * WWDGx)
Function description
Return current Watchdog Window Value (7 bits value)
Parameters
WWDGx: WWDG Instance
Return values
7: bit Watchdog Window value
Reference Manual to
LL API cross
reference:
CFR W LL_WWDG_GetWindow
LL_WWDG_IsActiveFlag_EWKUP
Function name
__STATIC_INLINE uint32_t LL_WWDG_IsActiveFlag_EWKUP
(WWDG_TypeDef * WWDGx)
Function description
Indicates if the WWDG Early Wakeup Interrupt Flag is set or not.
Parameters
WWDGx: WWDG Instance
Return values
State: of bit (1 or 0).
Notes
This bit is set by hardware when the counter has reached the
