ST STM32F2 User Manual

UM1940
LL TIM Generic Driver
DocID028236 Rev 2
1199/1371
IS_TIM_CLOCKSOURCE_ETRMODE1_INSTANCE(TIMx)
can be used to check whether or not a timer instance
supports external clock mode1.
Macro
IS_TIM_CLOCKSOURCE_ETRMODE2_INSTANCE(TIMx)
can be used to check whether or not a timer instance
supports external clock mode2.
Reference Manual to
LL API cross
reference:
SMCR SMS LL_TIM_SetClockSource
SMCR ECE LL_TIM_SetClockSource
LL_TIM_SetEncoderMode
Function name
__STATIC_INLINE void LL_TIM_SetEncoderMode
(TIM_TypeDef * TIMx, uint32_t EncoderMode)
Function description
Set the encoder interface mode.
Parameters
TIMx: Timer instance
EncoderMode: This parameter can be one of the following
values:
LL_TIM_ENCODERMODE_X2_TI1
LL_TIM_ENCODERMODE_X2_TI2
LL_TIM_ENCODERMODE_X4_TI12
Return values
None:
Notes
Macro IS_TIM_ENCODER_INTERFACE_INSTANCE(TIMx)
can be used to check whether or not a timer instance
supports the encoder mode.
Reference Manual to
LL API cross
reference:
SMCR SMS LL_TIM_SetEncoderMode
LL_TIM_SetTriggerOutput
Function name
__STATIC_INLINE void LL_TIM_SetTriggerOutput
(TIM_TypeDef * TIMx, uint32_t TimerSynchronization)
Function description
Set the trigger output (TRGO) used for timer synchronization .
Parameters
TIMx: Timer instance
TimerSynchronization: This parameter can be one of the
following values:
LL_TIM_TRGO_RESET
LL_TIM_TRGO_ENABLE
LL_TIM_TRGO_UPDATE
LL_TIM_TRGO_CC1IF
LL_TIM_TRGO_OC1REF
LL_TIM_TRGO_OC2REF
LL_TIM_TRGO_OC3REF
LL_TIM_TRGO_OC4REF
Return values
None:
Notes
Macro IS_TIM_MASTER_INSTANCE(TIMx) can be used to
check whether or not a timer instance can operate as a
