Field Documentation
uint32_t TIM_ClearInputConfigTypeDef::ClearInputState
TIM clear Input state. This parameter can be ENABLE or DISABLE
uint32_t TIM_ClearInputConfigTypeDef::ClearInputSource
TIM clear Input sources. This parameter can be a value of TIM_ClearInput_Source
uint32_t TIM_ClearInputConfigTypeDef::ClearInputPolarity
TIM Clear Input polarity. This parameter can be a value of TIM_ClearInput_Polarity
uint32_t TIM_ClearInputConfigTypeDef::ClearInputPrescaler
TIM Clear Input prescaler. This parameter can be a value of
TIM_ClearInput_Prescaler
uint32_t TIM_ClearInputConfigTypeDef::ClearInputFilter
TIM Clear Input filter. This parameter can be a number between Min_Data = 0x0 and
Max_Data = 0xF
45.1.8 TIM_SlaveConfigTypeDef
Data Fields
uint32_t SlaveMode
uint32_t InputTrigger
uint32_t TriggerPolarity
uint32_t TriggerPrescaler
uint32_t TriggerFilter
Field Documentation
uint32_t TIM_SlaveConfigTypeDef::SlaveMode
Slave mode selection This parameter can be a value of TIM_Slave_Mode
uint32_t TIM_SlaveConfigTypeDef::InputTrigger
Input Trigger source This parameter can be a value of TIM_Trigger_Selection
uint32_t TIM_SlaveConfigTypeDef::TriggerPolarity
Input Trigger polarity This parameter can be a value of TIM_Trigger_Polarity
uint32_t TIM_SlaveConfigTypeDef::TriggerPrescaler
Input trigger prescaler This parameter can be a value of TIM_Trigger_Prescaler
uint32_t TIM_SlaveConfigTypeDef::TriggerFilter
Input trigger filter This parameter can be a number between Min_Data = 0x0 and
Max_Data = 0xF
45.1.9 TIM_HandleTypeDef
Data Fields
TIM_TypeDef * Instance
TIM_Base_InitTypeDef Init
HAL_TIM_ActiveChannel Channel
DMA_HandleTypeDef * hdma
HAL_LockTypeDef Lock
__IO HAL_TIM_StateTypeDef State
Field Documentation
TIM_TypeDef* TIM_HandleTypeDef::Instance
Register base address
TIM_Base_InitTypeDef TIM_HandleTypeDef::Init
TIM Time Base required parameters
HAL_TIM_ActiveChannel TIM_HandleTypeDef::Channel
Active channel
