ST STM32F2 User Manual

UM1940
LL TIM Generic Driver
DocID028236 Rev 2
1193/1371
LL_TIM_IC_FILTER_FDIV1_N8
LL_TIM_IC_FILTER_FDIV2_N6
LL_TIM_IC_FILTER_FDIV2_N8
LL_TIM_IC_FILTER_FDIV4_N6
LL_TIM_IC_FILTER_FDIV4_N8
LL_TIM_IC_FILTER_FDIV8_N6
LL_TIM_IC_FILTER_FDIV8_N8
LL_TIM_IC_FILTER_FDIV16_N5
LL_TIM_IC_FILTER_FDIV16_N6
LL_TIM_IC_FILTER_FDIV16_N8
LL_TIM_IC_FILTER_FDIV32_N5
LL_TIM_IC_FILTER_FDIV32_N6
LL_TIM_IC_FILTER_FDIV32_N8
Return values
None:
Reference Manual to
LL API cross
reference:
CCMR1 IC1F LL_TIM_IC_SetFilter
CCMR1 IC2F LL_TIM_IC_SetFilter
CCMR2 IC3F LL_TIM_IC_SetFilter
CCMR2 IC4F LL_TIM_IC_SetFilter
LL_TIM_IC_GetFilter
Function name
__STATIC_INLINE uint32_t LL_TIM_IC_GetFilter (TIM_TypeDef
* TIMx, uint32_t Channel)
Function description
Get the input filter duration.
Parameters
TIMx: Timer instance
Channel: This parameter can be one of the following values:
LL_TIM_CHANNEL_CH1
LL_TIM_CHANNEL_CH2
LL_TIM_CHANNEL_CH3
LL_TIM_CHANNEL_CH4
Return values
Returned: value can be one of the following values:
LL_TIM_IC_FILTER_FDIV1
LL_TIM_IC_FILTER_FDIV1_N2
LL_TIM_IC_FILTER_FDIV1_N4
LL_TIM_IC_FILTER_FDIV1_N8
LL_TIM_IC_FILTER_FDIV2_N6
LL_TIM_IC_FILTER_FDIV2_N8
LL_TIM_IC_FILTER_FDIV4_N6
LL_TIM_IC_FILTER_FDIV4_N8
LL_TIM_IC_FILTER_FDIV8_N6
LL_TIM_IC_FILTER_FDIV8_N8
LL_TIM_IC_FILTER_FDIV16_N5
LL_TIM_IC_FILTER_FDIV16_N6
LL_TIM_IC_FILTER_FDIV16_N8
LL_TIM_IC_FILTER_FDIV32_N5
LL_TIM_IC_FILTER_FDIV32_N6
LL_TIM_IC_FILTER_FDIV32_N8
Reference Manual to
LL API cross
CCMR1 IC1F LL_TIM_IC_GetFilter
CCMR1 IC2F LL_TIM_IC_GetFilter
