HAL SMARTCARD Generic Driver
the smartcard clock. The value given in the register (5 significant bits) is multiplied by
2 to give the division factor of the source clock frequency. This parameter can be a
value of SMARTCARD_Prescaler
uint32_t SMARTCARD_InitTypeDef::GuardTime
Specifies the SmartCard Guard Time value in terms of number of baud clocks
uint32_t SMARTCARD_InitTypeDef::NACKState
Specifies the SmartCard NACK Transmission state. This parameter can be a value of
SMARTCARD_NACK_State
42.1.2 SMARTCARD_HandleTypeDef
Data Fields
USART_TypeDef * Instance
SMARTCARD_InitTypeDef Init
uint8_t * pTxBuffPtr
uint16_t TxXferSize
__IO uint16_t TxXferCount
uint8_t * pRxBuffPtr
uint16_t RxXferSize
__IO uint16_t RxXferCount
DMA_HandleTypeDef * hdmatx
DMA_HandleTypeDef * hdmarx
HAL_LockTypeDef Lock
__IO HAL_SMARTCARD_StateTypeDef gState
__IO HAL_SMARTCARD_StateTypeDef RxState
__IO uint32_t ErrorCode
Field Documentation
USART_TypeDef* SMARTCARD_HandleTypeDef::Instance
SMARTCARD_InitTypeDef SMARTCARD_HandleTypeDef::Init
uint8_t* SMARTCARD_HandleTypeDef::pTxBuffPtr
uint16_t SMARTCARD_HandleTypeDef::TxXferSize
__IO uint16_t SMARTCARD_HandleTypeDef::TxXferCount
uint8_t* SMARTCARD_HandleTypeDef::pRxBuffPtr
uint16_t SMARTCARD_HandleTypeDef::RxXferSize
__IO uint16_t SMARTCARD_HandleTypeDef::RxXferCount
DMA_HandleTypeDef* SMARTCARD_HandleTypeDef::hdmatx
DMA_HandleTypeDef* SMARTCARD_HandleTypeDef::hdmarx
HAL_LockTypeDef SMARTCARD_HandleTypeDef::Lock
__IO HAL_SMARTCARD_StateTypeDef SMARTCARD_HandleTypeDef::gState
__IO HAL_SMARTCARD_StateTypeDef SMARTCARD_HandleTypeDef::RxState
__IO uint32_t SMARTCARD_HandleTypeDef::ErrorCode
42.2 SMARTCARD Firmware driver API description
42.2.1 How to use this driver
The SMARTCARD HAL driver can be used as follows:
1. Declare a SMARTCARD_HandleTypeDef handle structure.
2. Initialize the SMARTCARD low level resources by implementing the
HAL_SMARTCARD_MspInit() API:
a. Enable the USARTx interface clock.
b. SMARTCARD pins configuration:
