UM1940
HAL DMA Extension Driver
DocID028236 Rev 2
201/1371
16 HAL DMA Extension Driver
16.1 DMAEx Firmware driver API description
16.1.1 How to use this driver
The DMA Extension HAL driver can be used as follows:
1. Start a multi buffer transfer using the HAL_DMA_MultiBufferStart() function for polling
mode or HAL_DMA_MultiBufferStart_IT() for interrupt mode. In Memory-to-Memory
transfer mode, Multi (Double) Buffer mode is not allowed. When Multi (Double) Buffer
mode is enabled the, transfer is circular by default. In Multi (Double) buffer mode, it is
possible to update the base address for the AHB memory port on the fly
(DMA_SxM0AR or DMA_SxM1AR) when the stream is enabled.
16.1.2 Extended features functions
This section provides functions allowing to:
Configure the source, destination address and data length and Start MultiBuffer DMA
transfer
Configure the source, destination address and data length and Start MultiBuffer DMA
transfer with interrupt
Change on the fly the memory0 or memory1 address.
This section contains the following APIs:
HAL_DMAEx_MultiBufferStart()
HAL_DMAEx_MultiBufferStart_IT()
HAL_DMAEx_ChangeMemory()
16.1.3 Detailed description of functions
HAL_DMAEx_MultiBufferStart
Function name
HAL_StatusTypeDef HAL_DMAEx_MultiBufferStart
(DMA_HandleTypeDef * hdma, uint32_t SrcAddress, uint32_t
DstAddress, uint32_t SecondMemAddress, uint32_t
DataLength)
Function description
Starts the multi_buffer DMA Transfer.
Parameters
hdma: : pointer to a DMA_HandleTypeDef structure that
contains the configuration information for the specified DMA
Stream.
SrcAddress: The source memory Buffer address
DstAddress: The destination memory Buffer address
SecondMemAddress: The second memory Buffer address
in case of multi buffer Transfer
DataLength: The length of data to be transferred from
source to destination
Return values
HAL: status
