UM1940
Correspondence
between API reg
isters and API
low-layer driver functi
ons
DocID028236 Re
v 2
1339
/1371
71.15
RTC
Table 39: Correspondence between RTC registers and RTC low-la
y
e
r driver functions
Register
Field
Function
ALRMAR
DT
LL_RTC_ALMA_GetDay
LL_RTC_ALMA_SetDay
DU
LL_RTC_ALMA_GetDay
LL_RTC_ALMA_GetWeekDay
LL_RTC_ALMA_SetDay
LL_RTC_ALMA_SetWeekDay
HT
LL_RTC_ALMA_ConfigTime
LL_RTC_ALMA_GetHour
LL_RTC_ALMA_GetTime
LL_RTC_ALMA_SetHour
HU
LL_RTC_ALMA_ConfigTime
LL_RTC_ALMA_GetHour
LL_RTC_ALMA_GetTime
LL_RTC_ALMA_SetHour
MNT
LL_RTC_ALMA_ConfigTime
LL_RTC_ALMA_GetMinute
LL_RTC_ALMA_GetTime
LL_RTC_ALMA_SetMinute
MNU
LL_RTC_ALMA_ConfigTime
LL_RTC_ALMA_GetMinute
LL_RTC_ALMA_GetTime
LL_RTC_ALMA_SetMinute
MSK1
LL_RTC_ALMA_GetMask
LL_RTC_ALMA_SetMask
MSK2
LL_RTC_ALMA_GetMask
LL_RTC_ALMA_SetMask
MSK3
LL_RTC_ALMA_GetMask
LL_RTC_ALMA_SetMask
MSK4
LL_RTC_ALMA_GetMask
LL_RTC_ALMA_SetMask
PM
LL_RTC_ALMA_ConfigTime
LL_RTC_ALMA_GetTimeFormat
LL_RTC_ALMA_SetTimeFormat
ST
LL_RTC_ALMA_ConfigTime
1338
1340
