UM1940
1340
/1371
DocID028236 Re
v 2
Register
Field
Function
LL_RTC_ALMA_GetSecond
LL_RTC_ALMA_GetTime
LL_RTC_ALMA_SetSecond
SU
LL_RTC_ALMA_ConfigTime
LL_RTC_ALMA_GetSecond
LL_RTC_ALMA_GetTime
LL_RTC_ALMA_SetSecond
W
DSEL
LL_RTC_ALMA_DisableWeekday
LL_RTC_ALMA_EnableWeekday
ALRMBR
DT
LL_RTC_ALMB_GetDay
LL_RTC_ALMB_SetDay
DU
LL_RTC_ALMB_GetDay
LL_RTC_ALMB_GetWeekDay
LL_RTC_ALMB_SetDay
LL_RTC_ALMB_SetWeekDay
HT
LL_RTC_ALMB_ConfigTime
LL_RTC_ALMB_GetHour
LL_RTC_ALMB_GetTime
LL_RTC_ALMB_SetHour
HU
LL_RTC_ALMB_ConfigTime
LL_RTC_ALMB_GetHour
LL_RTC_ALMB_GetTime
LL_RTC_ALMB_SetHour
MNT
LL_RTC_ALMB_ConfigTime
LL_RTC_ALMB_GetMinute
LL_RTC_ALMB_GetTime
LL_RTC_ALMB_SetMinute
MNU
LL_RTC_ALMB_ConfigTime
LL_RTC_ALMB_GetMinute
LL_RTC_ALMB_GetTime
LL_RTC_ALMB_SetMinute
MSK1
LL_RTC_ALMB_GetMask
LL_RTC_ALMB_SetMask
MSK2
LL_RTC_ALMB_GetMask
LL_RTC_ALMB_SetMask
MSK3
LL_RTC_ALMB_GetMask
1339
1341
