30 HAL NOR Generic Driver
30.1 NOR Firmware driver registers structures
30.1.1 NOR_IDTypeDef
Data Fields
uint16_t Manufacturer_Code
uint16_t Device_Code1
uint16_t Device_Code2
uint16_t Device_Code3
Field Documentation
uint16_t NOR_IDTypeDef::Manufacturer_Code
Defines the device's manufacturer code used to identify the memory
uint16_t NOR_IDTypeDef::Device_Code1
uint16_t NOR_IDTypeDef::Device_Code2
uint16_t NOR_IDTypeDef::Device_Code3
Defines the device's codes used to identify the memory. These codes can be
accessed by performing read operations with specific control signals and addresses
set.They can also be accessed by issuing an Auto Select command
30.1.2 NOR_CFITypeDef
Data Fields
uint16_t CFI_1
uint16_t CFI_2
uint16_t CFI_3
uint16_t CFI_4
Field Documentation
uint16_t NOR_CFITypeDef::CFI_1
< Defines the information stored in the memory's Common flash interface which
contains a description of various electrical and timing parameters, density information
and functions supported by the memory
uint16_t NOR_CFITypeDef::CFI_2
uint16_t NOR_CFITypeDef::CFI_3
uint16_t NOR_CFITypeDef::CFI_4
30.1.3 NOR_HandleTypeDef
Data Fields
FSMC_NORSRAM_TypeDef * Instance
FSMC_NORSRAM_EXTENDED_TypeDef * Extended
FSMC_NORSRAM_InitTypeDef Init
HAL_LockTypeDef Lock
__IO HAL_NOR_StateTypeDef State
Field Documentation
FSMC_NORSRAM_TypeDef* NOR_HandleTypeDef::Instance
Register base address
