ST STM32F2 User Manual

UM1940
LL GPIO Generic Driver
DocID028236 Rev 2
929/1371
LL_GPIO_PIN_14
LL_GPIO_PIN_15
Return values
Returned: value can be one of the following values:
LL_GPIO_MODE_INPUT
LL_GPIO_MODE_OUTPUT
LL_GPIO_MODE_ALTERNATE
LL_GPIO_MODE_ANALOG
Notes
I/O mode can be Input mode, General purpose output,
Alternate function mode or Analog.
Warning: only one pin can be passed as parameter.
Reference Manual to
LL API cross
reference:
MODER MODEy LL_GPIO_GetPinMode
LL_GPIO_SetPinOutputType
Function name
__STATIC_INLINE void LL_GPIO_SetPinOutputType
(GPIO_TypeDef * GPIOx, uint32_t PinMask, uint32_t
OutputType)
Function description
Configure gpio output type for several pins on dedicated port.
Parameters
GPIOx: GPIO Port
PinMask: This parameter can be a combination of the
following values:
LL_GPIO_PIN_0
LL_GPIO_PIN_1
LL_GPIO_PIN_2
LL_GPIO_PIN_3
LL_GPIO_PIN_4
LL_GPIO_PIN_5
LL_GPIO_PIN_6
LL_GPIO_PIN_7
LL_GPIO_PIN_8
LL_GPIO_PIN_9
LL_GPIO_PIN_10
LL_GPIO_PIN_11
LL_GPIO_PIN_12
LL_GPIO_PIN_13
LL_GPIO_PIN_14
LL_GPIO_PIN_15
LL_GPIO_PIN_ALL
OutputType: This parameter can be one of the following
values:
LL_GPIO_OUTPUT_PUSHPULL
LL_GPIO_OUTPUT_OPENDRAIN
Return values
None:
Notes
Output type as to be set when gpio pin is in output or
alternate modes. Possible type are Push-pull or Open-drain.
Reference Manual to
LL API cross
OTYPER OTy LL_GPIO_SetPinOutputType
