UM1940
Correspondence
between API reg
isters and API
low-layer driver functi
ons
DocID028236 Re
v 2
1351
/1371
71.18
TIM
Table 42: Correspondence between TIM registers and TIM low-la
y
e
r driver functions
Register
Field
Function
ARR
ARR
LL_TIM_GetAutoReload
LL_TIM_SetAutoReload
BDTR
AOE
LL_TIM_DisableAutomaticOutput
LL_TIM_EnableAutomaticOutput
LL_TIM_IsEnabledAutomaticOutput
BKE
LL_TIM_DisableBRK
LL_TIM_EnableBRK
BKP
LL_TIM_ConfigBRK
DTG
LL_TIM_OC_SetDeadTime
LOCK
LL_TIM_CC_SetLockLevel
MOE
LL_TIM_DisableAllOutputs
LL_TIM_EnableAllOutputs
LL_TIM_IsEnabledAllOutputs
OSSI
LL_TIM_SetOffStates
OSSR
LL_TIM_SetOffStates
CCER
CC1E
LL_TIM_CC_DisableChannel
LL_TIM_CC_EnableChannel
LL_TIM_CC_IsEnabledChannel
CC1NE
LL_TIM_CC_DisableChannel
LL_TIM_CC_EnableChannel
LL_TIM_CC_IsEnabledChannel
CC1NP
LL_TIM_IC_Config
LL_TIM_IC_GetPolarity
LL_TIM_IC_SetPolarity
LL_TIM_OC_GetPolarity
LL_TIM_OC_SetPolarity
CC1P
LL_TIM_IC_Config
LL_TIM_IC_GetPolarity
LL_TIM_IC_SetPolarity
LL_TIM_OC_ConfigOutput
LL_TIM_OC_GetPolarity
LL_TIM_OC_SetPolarity
CC2E
LL_TIM_CC_DisableChannel
LL_TIM_CC_EnableChannel
1350
1352
