uint32_t SPI_InitTypeDef::CRCPolynomial
Specifies the polynomial used for the CRC calculation. This parameter must be a
number between Min_Data = 0 and Max_Data = 65535
43.1.2 __SPI_HandleTypeDef
Data Fields
SPI_TypeDef * Instance
SPI_InitTypeDef Init
uint8_t * pTxBuffPtr
uint16_t TxXferSize
__IO uint16_t TxXferCount
uint8_t * pRxBuffPtr
uint16_t RxXferSize
__IO uint16_t RxXferCount
void(* RxISR
void(* TxISR
DMA_HandleTypeDef * hdmatx
DMA_HandleTypeDef * hdmarx
HAL_LockTypeDef Lock
__IO HAL_SPI_StateTypeDef State
__IO uint32_t ErrorCode
Field Documentation
SPI_TypeDef* __SPI_HandleTypeDef::Instance
SPI_InitTypeDef __SPI_HandleTypeDef::Init
uint8_t* __SPI_HandleTypeDef::pTxBuffPtr
uint16_t __SPI_HandleTypeDef::TxXferSize
__IO uint16_t __SPI_HandleTypeDef::TxXferCount
uint8_t* __SPI_HandleTypeDef::pRxBuffPtr
uint16_t __SPI_HandleTypeDef::RxXferSize
__IO uint16_t __SPI_HandleTypeDef::RxXferCount
void(* __SPI_HandleTypeDef::RxISR)(struct __SPI_HandleTypeDef *hspi)
void(* __SPI_HandleTypeDef::TxISR)(struct __SPI_HandleTypeDef *hspi)
DMA_HandleTypeDef* __SPI_HandleTypeDef::hdmatx
DMA_HandleTypeDef* __SPI_HandleTypeDef::hdmarx
HAL_LockTypeDef __SPI_HandleTypeDef::Lock
__IO HAL_SPI_StateTypeDef __SPI_HandleTypeDef::State
__IO uint32_t __SPI_HandleTypeDef::ErrorCode
43.2 SPI Firmware driver API description
43.2.1 How to use this driver
The SPI HAL driver can be used as follows:
1. Declare a SPI_HandleTypeDef handle structure, for example: SPI_HandleTypeDef
hspi;
2. Initialize the SPI low level resources by implementing the HAL_SPI_MspInit() API:
a. Enable the SPIx interface clock
b. SPI pins configuration
Enable the clock for the SPI GPIOs
Configure these SPI pins as alternate function push-pull
c. NVIC configuration if you need to use interrupt process
