ST STM32F2 User Manual

LL TIM Generic Driver
UM1940
1196/1371
DocID028236 Rev 2
LL_TIM_IC_GetCaptureCH1
Function name
__STATIC_INLINE uint32_t LL_TIM_IC_GetCaptureCH1
(TIM_TypeDef * TIMx)
Function description
Get captured value for input channel 1.
Parameters
TIMx: Timer instance
Return values
CapturedValue: (between Min_Data=0 and
Max_Data=65535)
Notes
In 32-bit timer implementations returned captured value can
be between 0x00000000 and 0xFFFFFFFF.
Macro IS_TIM_32B_COUNTER_INSTANCE(TIMx) can be
used to check whether or not a timer instance supports a 32
bits counter.
Macro IS_TIM_CC1_INSTANCE(TIMx) can be used to check
whether or not input channel 1 is supported by a timer
instance.
Reference Manual to
LL API cross
reference:
CCR1 CCR1 LL_TIM_IC_GetCaptureCH1
LL_TIM_IC_GetCaptureCH2
Function name
__STATIC_INLINE uint32_t LL_TIM_IC_GetCaptureCH2
(TIM_TypeDef * TIMx)
Function description
Get captured value for input channel 2.
Parameters
TIMx: Timer instance
Return values
CapturedValue: (between Min_Data=0 and
Max_Data=65535)
Notes
In 32-bit timer implementations returned captured value can
be between 0x00000000 and 0xFFFFFFFF.
Macro IS_TIM_32B_COUNTER_INSTANCE(TIMx) can be
used to check whether or not a timer instance supports a 32
bits counter.
Macro IS_TIM_CC2_INSTANCE(TIMx) can be used to check
whether or not input channel 2 is supported by a timer
instance.
Reference Manual to
LL API cross
reference:
CCR2 CCR2 LL_TIM_IC_GetCaptureCH2
LL_TIM_IC_GetCaptureCH3
Function name
__STATIC_INLINE uint32_t LL_TIM_IC_GetCaptureCH3
(TIM_TypeDef * TIMx)
Function description
Get captured value for input channel 3.
Parameters
TIMx: Timer instance
Return values
CapturedValue: (between Min_Data=0 and
Max_Data=65535)
