ST STM32F2 User Manual

UM1940
HAL TIM Extension Driver
DocID028236 Rev 2
633/1371
Configure Complementary channels, break features and dead time.
Configure Master and the Slave synchronization.
Configure the commutation event in case of use of the Hall sensor interface.
Configure the DMA Burst Mode.
This section contains the following APIs:
HAL_TIMEx_ConfigCommutationEvent()
HAL_TIMEx_ConfigCommutationEvent_IT()
HAL_TIMEx_ConfigCommutationEvent_DMA()
HAL_TIMEx_MasterConfigSynchronization()
HAL_TIMEx_ConfigBreakDeadTime()
HAL_TIMEx_RemapConfig()
46.2.8 Extension Callbacks functions
This section provides Extension TIM callback functions:
Timer Commutation callback
Timer Break callback
This section contains the following APIs:
HAL_TIMEx_CommutationCallback()
HAL_TIMEx_BreakCallback()
TIMEx_DMACommutationCplt()
46.2.9 Extension Peripheral State functions
This subsection permits to get in run-time the status of the peripheral and the data flow.
This section contains the following APIs:
HAL_TIMEx_HallSensor_GetState()
46.2.10 Detailed description of functions
HAL_TIMEx_HallSensor_Init
Function name
HAL_StatusTypeDef HAL_TIMEx_HallSensor_Init
(TIM_HandleTypeDef * htim, TIM_HallSensor_InitTypeDef *
sConfig)
Function description
Initializes the TIM Hall Sensor Interface and create the associated
handle.
Parameters
htim: pointer to a TIM_HandleTypeDef structure that
contains the configuration information for TIM module.
sConfig: TIM Hall Sensor configuration structure
Return values
HAL: status
HAL_TIMEx_HallSensor_DeInit
Function name
HAL_StatusTypeDef HAL_TIMEx_HallSensor_DeInit
(TIM_HandleTypeDef * htim)
Function description
DeInitializes the TIM Hall Sensor interface.
Parameters
htim: pointer to a TIM_HandleTypeDef structure that
