ST STM32F2 User Manual

HAL IRDA Generic Driver
UM1940
330/1371
DocID028236 Rev 2
Polling mode IO operation
Send an amount of data in blocking mode using HAL_IRDA_Transmit()
Receive an amount of data in blocking mode using HAL_IRDA_Receive()
Interrupt mode IO operation
Send an amount of data in non blocking mode using HAL_IRDA_Transmit_IT()
At transmission end of transfer HAL_IRDA_TxCpltCallback is executed and user can
add his own code by customization of function pointer HAL_IRDA_TxCpltCallback
Receive an amount of data in non blocking mode using HAL_IRDA_Receive_IT()
At reception end of transfer HAL_IRDA_RxCpltCallback is executed and user can add
his own code by customization of function pointer HAL_IRDA_RxCpltCallback
In case of transfer Error, HAL_IRDA_ErrorCallback() function is executed and user
can add his own code by customization of function pointer HAL_IRDA_ErrorCallback
DMA mode IO operation
Send an amount of data in non blocking mode (DMA) using
HAL_IRDA_Transmit_DMA()
At transmission end of transfer HAL_IRDA_TxCpltCallback is executed and user can
add his own code by customization of function pointer HAL_IRDA_TxCpltCallback
Receive an amount of data in non blocking mode (DMA) using
HAL_IRDA_Receive_DMA()
At reception end of transfer HAL_IRDA_RxCpltCallback is executed and user can add
his own code by customization of function pointer HAL_IRDA_RxCpltCallback
In case of transfer Error, HAL_IRDA_ErrorCallback() function is executed and user
can add his own code by customization of function pointer HAL_IRDA_ErrorCallback
IRDA HAL driver macros list
Below the list of most used macros in IRDA HAL driver.
__HAL_IRDA_ENABLE: Enable the IRDA peripheral
__HAL_IRDA_DISABLE: Disable the IRDA peripheral
__HAL_IRDA_GET_FLAG : Checks whether the specified IRDA flag is set or not
__HAL_IRDA_CLEAR_FLAG : Clears the specified IRDA pending flag
__HAL_IRDA_ENABLE_IT: Enables the specified IRDA interrupt
__HAL_IRDA_DISABLE_IT: Disables the specified IRDA interrupt
You can refer to the IRDA HAL driver header file for more useful macros
26.2.2 Initialization and Configuration functions
This subsection provides a set of functions allowing to initialize the USARTx or the UARTy
in IrDA mode.
For the asynchronous mode only these parameters can be configured:
BaudRate
WordLength
Parity: If the parity is enabled, then the MSB bit of the data written in the data
register is transmitted but is changed by the parity bit. Depending on the frame
