UM1940
Correspondence
between API reg
isters and API
low-layer driver functi
ons
DocID028236 Re
v 2
1335
/1371
Register
Field
Function
PVDO
LL_PWR_IsActiveFlag_PVDO
SBF
LL_PWR_IsActiveFlag_SB
W
UF
LL_PWR_IsActiveFlag_WU
71.13
RCC
Table 37: Correspondence between RCC registers and RCC low
-lay
er driver functions
Register
Field
Function
BDCR
BDRST
LL_RCC_ForceBackupDomainReset
LL_RCC_ReleaseBackupDomainReset
LSEBYP
LL_RCC_LSE_DisableBypass
LL_RCC_LSE_EnableBypass
LSEON
LL_RCC_LSE_Disable
LL_RCC_LSE_Enable
LSERDY
LL_RCC_LSE_IsReady
RTCEN
LL_RCC_DisableRTC
LL_RCC_EnableRTC
LL_RCC_IsEnabledRTC
RTCSEL
LL_RCC_GetRTCClockSource
LL_RCC_SetRTCClockSource
CFGR
HPRE
LL_RCC_GetAHBPrescaler
LL_RCC_SetAHBPrescaler
I2SSRC
LL_RCC_GetI2SClockSource
LL_RCC_SetI2SClockSource
MCO1
LL_RCC_ConfigMCO
MCO1PRE
LL_RCC_ConfigMCO
MCO2
LL_RCC_ConfigMCO
MCO2PRE
LL_RCC_ConfigMCO
PPRE1
LL_RCC_GetAPB1Prescaler
LL_RCC_SetAPB1Prescaler
PPRE2
LL_RCC_GetAPB2Prescaler
LL_RCC_SetAPB2Prescaler
RTCPRE
LL_RCC_GetRTC_HSEPrescaler
LL_RCC_SetRTC_HSEPrescaler
SW
LL_RCC_SetSysClkSource
SWS
LL_RCC_GetSysClkSource
CIR
CSSC
LL_RCC_ClearFlag_HSECSS
1334
1336
