ST STM32F2 User Manual

UM1940
LL TIM Generic Driver
DocID028236 Rev 2
1187/1371
Reference Manual to
LL API cross
reference:
CCR1 CCR1 LL_TIM_OC_SetCompareCH1
LL_TIM_OC_SetCompareCH2
Function name
__STATIC_INLINE void LL_TIM_OC_SetCompareCH2
(TIM_TypeDef * TIMx, uint32_t CompareValue)
Function description
Set compare value for output channel 2 (TIMx_CCR2).
Parameters
TIMx: Timer instance
CompareValue: between Min_Data=0 and
Max_Data=65535
Return values
None:
Notes
In 32-bit timer implementations compare value can be
between 0x00000000 and 0xFFFFFFFF.
Macro IS_TIM_32B_COUNTER_INSTANCE(TIMx) can be
used to check whether or not a timer instance supports a 32
bits counter.
Macro IS_TIM_CC2_INSTANCE(TIMx) can be used to check
whether or not output channel 2 is supported by a timer
instance.
Reference Manual to
LL API cross
reference:
CCR2 CCR2 LL_TIM_OC_SetCompareCH2
LL_TIM_OC_SetCompareCH3
Function name
__STATIC_INLINE void LL_TIM_OC_SetCompareCH3
(TIM_TypeDef * TIMx, uint32_t CompareValue)
Function description
Set compare value for output channel 3 (TIMx_CCR3).
Parameters
TIMx: Timer instance
CompareValue: between Min_Data=0 and
Max_Data=65535
Return values
None:
Notes
In 32-bit timer implementations compare value can be
between 0x00000000 and 0xFFFFFFFF.
Macro IS_TIM_32B_COUNTER_INSTANCE(TIMx) can be
used to check whether or not a timer instance supports a 32
bits counter.
Macro IS_TIM_CC3_INSTANCE(TIMx) can be used to check
whether or not output channel is supported by a timer
instance.
Reference Manual to
LL API cross
reference:
CCR3 CCR3 LL_TIM_OC_SetCompareCH3
LL_TIM_OC_SetCompareCH4
Function name
__STATIC_INLINE void LL_TIM_OC_SetCompareCH4
